Mercedes-Benz Arocs 2136 A 4x4 | Fuel Tank | STOCK | 2 units | 12.000L

Mercedes-Benz Arocs 2136 A 4x4 Fuel Tanker | 12,000L | EURO-3 | STOCK

The Mercedes-Benz Arocs 2136 A 4x4 Fuel Tanker is for sale and configured for professional fuel distribution in demanding on- and off-road environments. Powered by the proven Mercedes-Benz OM460 12.8-litre EURO-3 engine producing 360HP and 1,800 Nm of torque, this permanent 4x4 truck combines a heavy-duty Grounder chassis with a 12,000-litre two-compartment fuel tanker body.

The vehicle features reinforced axle capacity and an adapted tyre configuration to support a higher operating weight in demanding terrain. Together with permanent all-wheel drive, differential locks, factory PTO and specialised hot-climate equipment, this Arocs provides a dependable fuel supply solution for mining, construction, infrastructure, energy and remote project operations. Available through Schaften Automotive for worldwide export.

QUICK HIGHLIGHTS
? Mercedes-Benz Arocs 2136 A 4x4
? Permanent All-Wheel Drive
? Mercedes-Benz OM460 12.8L EURO III Engine
? 360 HP (265 kW)
? 1,800 Nm Torque
? Mercedes-Benz G 260-16 Manual Transmission
? Grounder Off-Road Specification
? N3G Off-Road Vehicle Classification
? Reinforced Axle & Tyre Configuration
? Increased Weight Capacity for Off-Road Operations
? 12,000-Litre Fuel Tanker Body
? Two Separate 6,000-Litre Compartments
? Hydraulic Fuel Delivery Pump
? Approx. 400–500 L/min Pump Capacity
? Integrated Fuel Metering System
? 30-Metre Fuel Hose Reel
? Factory Mercedes-Benz PTO
? ADR Type Class AT
? Hot Climate & Dust Protection Package
? Ready for Worldwide Export

Built for Professional Fuel Distribution
Reliable fuel supply becomes critical when equipment operates far away from conventional filling stations.

The Mercedes-Benz Arocs 2136 A combines permanent four-wheel drive with a purpose-built 12,000-litre fuel tanker system developed for professional fuel transport and distribution.

The tanker is divided into two independent 6,000-litre compartments, providing a practical solution for organised fuel management during daily operations. Internal anti-surge baffles help control liquid movement during transport, while the heavy-duty steel tank construction provides the durability required for intensive commercial use.

This configuration allows fuel to be transported directly to machinery, generators, construction equipment and project vehicles operating in remote locations.

12,000-Litre Heavy-Duty Fuel Tanker
Fuel distribution requires more than simply carrying fuel from one location to another.

The tanker body is manufactured from heavy-duty mild steel with a 5 mm tank shell and reinforced 6 mm dished front and rear sections. Internal lateral and longitudinal anti-surge baffles increase stability by controlling fuel movement while the truck is travelling across uneven terrain.

Both 6,000-litre compartments include dedicated filling and monitoring equipment. Flame-proof ventilation, spill protection around the upper access points and protective tank-top construction contribute to safe and practical daily operation.

The complete tanker is installed on a dedicated subframe using heavy-duty saddle supports and elastic mounting connections designed around the truck chassis.

Hydraulic Pump, Metering System & Hose Equipment
Efficient refuelling depends on controlled fuel delivery.

The tanker is equipped with a hydraulically driven fuel pump providing an approximate delivery capacity of 400–500 litres per minute at 5–6 bar. Hydraulic power is supplied through the factory-installed Mercedes-Benz PTO, creating an integrated driveline solution for the tanker system. The hydraulic installation includes the necessary pump, controls, return filtration, oil cooling and associated components.

Fuel can be discharged through the pressurised pump system or by gravity, depending on operational requirements. An integrated flow-metering system allows operators to monitor fuel delivery, while the manual hose reel provides approximately 30 metres of 1-inch hose with filling nozzle for direct refuelling.

Permanent 4x4 Grounder Configuration
Fuel is often required exactly where conventional road vehicles reach their limits.

The Arocs 2136 A uses a permanent 4x4 drivetrain with a Mercedes-Benz VG 2800 transfer case, front differential lock and heavy-duty planetary rear axle. The final vehicle configuration combines reinforced axle capacity with an adapted tyre specification to provide additional weight capacity during demanding off-road operations.

Together with the Grounder specification, robust steel suspension and increased ground clearance, this creates a chassis developed for mining roads, construction sites, industrial locations and remote infrastructure projects. The Mercedes-Benz G 260-16 manual transmission provides direct control over power delivery, while the 360 HP OM460 engine delivers 1,800 Nm of torque for dependable operation under continuous load.

Designed for Hot & Dusty Environments
Remote fuel distribution often takes place under difficult environmental conditions.

This Mercedes-Benz Arocs is factory-equipped with a cooling package developed for very hot regions, an elevated air intake behind the cab, cyclone filtration for coarse dust, construction-site air filtration and an additional chassis-mounted fuel pre-filter. These systems help protect critical engine and fuel components when operating in environments where heat, dust and contaminated fuel can directly affect vehicle reliability. Steel bumper corners, protective equipment and reinforced construction components further support operation in demanding project environments.

Ideal Applications
The Mercedes-Benz Arocs 2136 A 4x4 Fuel Tanker is particularly suitable for:
- Mining & Quarry Operations
- Construction & Infrastructure Projects
- Oil, Gas & Energy Operations
- Heavy Equipment & Machinery Refuelling
- Generator & Industrial Fuel Supply
- Remote Site Logistics

Technical Specifications
- Vehicle: Mercedes-Benz Arocs 5 2136 A
- Vehicle Type: 12,000-Litre Fuel Tanker
- Drive Configuration: Permanent 4x4 All-Wheel Drive
- Engine: Mercedes-Benz OM460 Inline 6
- Displacement: 12.8 Litres
- Power: 360 HP (265 kW) Torque 1,800 Nm
- Emission Standard: EURO III
- Transmission: Mercedes-Benz G 260-16
- Gearshift: Manual
- Transfer Case: Mercedes-Benz VG 2800-3W
- Gross Vehicle Weight: 21,000 kg
- Axle Configuration: Reinforced for Heavy-Duty Off-Road Operation
- Wheelbase: 4,200 mm
- Tank Capacity: Approx. 12,000 Litres
- Compartments: 2 × 6,000 Litres
- Tank Material: Heavy-Duty Mild Steel
- Tank Shell: 5 mm Steel
- Front & Rear Tank Sections: 6 mm Steel
- Pump Capacity: Approx. 400–500 L/min @ 5–6 bar
- Pump Drive: Hydraulic via Factory PTO
- Metering System: Integrated Fuel Flow Meter
- Hose Reel: Approx. 30 m × 1" with Filling Nozzle
- PTO: Mercedes-Benz MB131-2c
- Chassis Fuel Capacity: 290 Litres
- Cab: ClassicSpace M-Cab
- Vehicle Classification: N3G Off-Road / Grounder
- ADR Classification: Type AT
- Steering: Left-Hand Drive

Why Buy from Schaften Automotive?
Since 1977, Schaften Automotive has specialised in supplying premium commercial vehicles from leading European manufacturers. With more than 150 vehicles in stock, we offer immediate availability for customers worldwide.

From export documentation and international transport to custom-built vehicle bodies assembled according to Dutch quality standards, our experienced in-house team manages the complete process—providing one reliable partner from purchase to delivery.

Availability & Worldwide Export
Looking for a Mercedes-Benz Arocs 2136 A 4x4 fuel tanker for sale or a 12,000-litre fuel truck for demanding international operations?

This Arocs combines proven Mercedes-Benz all-wheel-drive technology with a complete mobile fuel distribution system, including two fuel compartments, hydraulic pumping, metering equipment and dedicated hose systems.

Its reinforced off-road configuration makes the vehicle particularly suitable for customers operating beyond conventional road networks where reliable fuel supply is essential.

Schaften Automotive supports worldwide export, documentation, international transport and vehicle preparation, providing one reliable partner from purchase to final delivery.
